ford coyote billet CRANKSHAFTS
BC Ford Coyote crankshafts are available in 4340 steel billet (up to 3000whp) and EN40B steel for power levels in excess of 3500+whp. CNC machined on state of the art, 5 axis Mazak Integrex 300-IV CNC machines to exacting tolerances (.0001"). Every crankshaft features large radius journals that add rigidity for high horsepower, high boost, high rpm applications. Gun drilled, CNC ground oil holes feature a smooth surface for extra oiling, tear dropped for added oil scoop, cross drilled for priority main feeding to the rods and micro polished to a mirror finish for optimum bearing lubricity. All cranks are stress relieved, shot peened, magna flux inspected and nitrided (multi step heat treatment) for ultimate performance. Fully profiled counterweights are designed for reduced windage through the crankcase creating less oil resistance for better rpm potential. BC also offers a Micro Polish finish that not only increases oil shedding, while decreasing oil foaming and parasitic losses but this polishing process enhances the ion nitriding, increasing overall tensile strength by 10% over the standard BC crankshafts. |
 |
|
Part # |
|
Description # |
|
Stroke |
|
Crank Pin |
|
Main |
|
Buy Now |
|
Status |
|
|
| BC5421B-3650 |
CRANKSHAFT - Ford Coyote - 52-58 lbs - EN40B STEEL BILLET |
3.650" |
Specify |
2.657" |
 |
In-Stock |
|
| BC5428B-3650 |
CRANKSHAFT - Ford Coyote - 52-58 lbs - 4340 STEEL BILLET |
3.650" |
2.100" |
2.559" |
|
In-Stock |
|
|
|
FORD COYOTE CRANKSHAFTS
BC crankshafts are made from the finest, aerospace grade 4340 steel billet material. CNC machined on state of the art, 5 axis Mazak Integrex 300-IV CNC machines to exacting tolerances (.0001"). Every crankshaft features large radius journals that add rigidity for high horsepower, high boost, high rpm applications. Gun drilled, CNC ground oil holes feature a smooth surface for extra oiling, tear dropped for added oil scoop, cross drilled for priority main feeding to the rods and micro polished to a mirror finish for optimum bearing lubricity. All cranks are stress relieved, shot peened, magna flux inspected and nitrided (multi step heat treatment) for ultimate performance. Fully profiled counterweights are designed for reduced windage through the crankcase creating less oil resistance for better rpm potential. |
 |
|
|
Part # |
|
Description # |
|
Stroke |
|
Crank Pin |
|
Main |
|
Buy Now |
|
Status |
|
|
| BC5425-3500 |
CRANKSHAFT – Ford Coyote, 4340 Billet w/2.086" Crank Pin (OEM) |
3.500" |
2.086" |
2.660" |
|
In-Stock |
|
| BC5425-3650 |
CRANKSHAFT - Ford Coyote, 4340 Billet w/ 2.086" Crank Pin (OEM) |
3.650" |
2.086" |
2.660" |
|
In-Stock |
|
| BC5428 |
CRANKSHAFT – Ford Coyote, 4340 Billet w/1.888" Crank Pin |
3.750" |
1.888" |
2.660" |
|
In-Stock |
|
| BC5429 |
CRANKSHAFT - Ford Coyote, 4340 Billet w/1.888" Crank Pin |
3.875" |
1.888" |
2.660" |
|
In-Stock |
|
|
|
